TECHNICAL SPECIFICATIONS
Type: Galilean
Binocular: Straight/ 180 degree Tiltable( Optional)
Objective: Apochromatic F-250 Standard ( F200 on request)
Stereoscopic Base: 22m
Eye Piece: 12.5x wide field high eye point
Magnification: 25x,16x,10x,6x,4x
Light Source: Cold Light through Fiber Optic light guide
Bulb: LED
Illumination Field: 80,000 Lux at 250mm objective with auto cut off switch
Light Intensity: Built-in heat absorbing filter ( Blue,Green optional)
Total Height ( Eye Point) : Max.1870mm/ Min 1350mm
Power Supply: 230 V 50 Hz single phase AC ( 110 V AC optional)
Weight: 80 Kg
